LT-260 2-Channel Amplifier
LT-260 2-Channel Amplifier
LT-260 2-Channel Amplifier
LT-260 2-Channel Amplifier

LT-260 2-Channel Amplifier

R 1,099.00
Tax included. Shipping calculated at checkout.

Features

  • 2 channel car audio power amplifier
  • 2 ohm stable in stereo mode
  • Bass boost control
  • Gain control
  • High/Low pass frequency control
  • Mosfet power supply
  • Low level input
  • Filter select switch
  • RCA input
  • Thermal protection
  • Short circuit protection
  • Led power and protection status indicator



Technical Specifications

Parameter Specification
Amplifier Class AB Class
Supply Voltage 11~15V DC
MAX Output Power 260W
Power Output @ 4 Ohm 60W x 2 Channel
Power Output @ 2 Ohm 90W x 2 Channel
Bridge Output @ 4 Ohm 180W x 1 Channel
Frequency Response (±2dB) 10Hz~30kHz
Signal to Noise Ratio >96dB
Input Impedance 20K ohms
Input Sensitivity 200mV~8V
Gain Level MIN/MAX
Total Harmonic Distortion <0.05%
RCA Input
 2 Channel
High Pass Frequency
 50Hz~250Hz
Low Pass Frequency 50Hz~250Hz
Bass Boost 0/+6/+12 dB
Recommended Fuse Type 30A x 1
Weight 1.80kg
Dimensions (LxWxH) 220x190x55 mm
